Strange HD 9″ Ford Housing Bolt-in For 2005-2014 Mustang Complete With Mounts & Ends

Description Note Upper mount is moved forward .400″ and upward .400″ Aftermarket adjustable upper control arm must be used Pinion offset is .125″ to passenger side Information Required Housing width Type of housing ends Center Housing – H1112 * • Constructed from .141″ mild steel • Heavy duty .282″ thick face plate • Internal gussets provide rigidity and support axle tubes • Slots allow exceptional weld contact of housing to tubes • Extended cover provides clearance for 9″ & 9 1/2″ gear sets * Modified for this application Fill & Drain plugs –  • Facilitate fluid changes • Allows for inspection of ring gear Housing Tubing –  • DOM 1026 steel • 3.250″ OD x .250″ wall thickness Vent –  • Prevents build-up of internal pressure • Ensures sealing integrity 2005-2014 Mustang Mounts • Strange HD upper control arm mount • Lower control arm mounts • Spring mounts • Shock mounts • Panhard bar mount • Bump stop mounts Choice of Housing Ends – H1148 / H1137 • Forged chrome moly • Accept 3.150″ bearings • Other Strange housing ends are also available Professionally Welded • Jig welded to ensure proper alignment • Tubes internally & externally welded to housing • Provides maximum support & rigidity Related Components Lube Locker® gasket….. Axle Packages Alloy……………………… P3102 / P3104 Pro Race……………….. P1007 / P1008 Brake Adapter Kit For tapered bearings… B1706NC For ball bearings………. B1706NCB See Our Full Line of Center Sections Available for Drag Race Only, Street / Track, and Performance Street Vehicles. This  may be subject to additional freight charges from Strange Engineering. Call our sales team or complete housing form to start your order.
